FIELD NOTES ISSUE 01

JOINs
without
surprises.

A visual companion for seeing row matches, missing keys, and fanout before your totals betray you.

Tsumugi raising one finger to correct a SQL mistake
Tsumugi turning with a field notebook
Black-and-white manga panel of Tsumugi catching duplicated database rows
Want more collectible plates? Vote for the instructor fan pack.

CASE FILE 01 KEY CARDINALITY

A duplicate lookup key
changed the result.

A duplicated customer key made two of four orders match twice, producing six input rows for SUM().

Predict the row pairs before you touch the aggregate.

02 RELATIONS BETWEEN STAGES

A query builds a new row set.

SQL does not save and update one value at a time like a Python loop. Each logical stage accepts a relation and produces another relation.

01FROM + JOINbuild candidate row pairs
02WHEREdiscard pairs that fail
03GROUP +
HAVING
form groups, then filter them
04SELECT +
DISTINCT
project the final row shape
05ORDER BYarrange the final rows
VARIABLE INSTINCT
total = total + order.amount

One mutable value changes over time.

RELATIONAL INSTINCT
SELECT customer_id, SUM(total)
FROM joined_rows
GROUP BY customer_id;

Define the input relation and output grain before applying the aggregate.

03 BEFORE THE JOIN

Read the key constraints
before the JOIN.

A primary key identifies one row. A foreign key points at that identity. The foreign key may repeat because one order can own many fills.

PARENT TABLE

orders

order_idPKunique · not null
created_atone order fact
CHILD TABLE

fills

fill_idPKone fill identity
order_idFKmay repeat
01

Primary key

orders.order_id is the identity of an order. It cannot be NULL or duplicated.

02

Foreign key

fills.order_id says which order a fill belongs to. Several fills may point to the same order.

03

Join condition

o.order_id = f.order_id compares values. It does not require both columns to be primary keys.

04 THE PAIRING PROMISE

A JOIN produces one row
for each matching pair.

For every row on one side, SQL finds all rows on the other side that satisfy the ON condition. Each match becomes one output row.

SELECT o.id, c.name, o.total FROM orders o JOIN customers c ON c.id = o.customer_id;
LEFT INPUT

orders

Four order rows waiting for a customer match
idcustomer_idtotal
LOOKUP

customers

One row per customer key
idname
1

Order 101 carries customer_id = 1.

2

The lookup contains exactly one id = 1.

3

One match means one joined row. The database repeats this search for every order.

JOIN OUTPUT

Four matches become four rows

4 rows
The query result when customer IDs are unique
order_idnametotal

05 CHOOSE THE PRESERVED SIDE

JOIN type decides which non-matches survive.

Skip the Venn diagram. Ask which row pairs qualify, then decide which unmatched input rows must still appear.

INNER

Matched pairs only

Unmatched rows disappear from both inputs.

Use when the relationship must exist.
LEFT

Preserve the left

Every left row survives. Missing right values become synthetic NULLs.

Use for “all customers, even zero orders.”
FULL

Preserve both

Keep unmatched rows from each input after the matched pairs.

Use for reconciliation.
CROSS

Every possible pair

m rows × n rows = m × n outputs.

Use to manufacture an expected grid.

06 THE MISSING MATCH

LEFT JOIN keeps the left row alive.

When no fill matches, SQL still emits the order. Every requested column from the missing right side appears as NULL in the result.

SELECT o.order_id, f.fill_id FROM orders o LEFT JOIN fills f ON f.order_id = o.order_id;
order 101two matching fills
101 · F1101 · F2
order 102zero matching fills
102 · NULL
LEFT JOIN OUTPUT

The NULL is a placeholder in the result

3 rows
Two fills for order 101 and one unmatched output row for order 102
order_idfill_idwhat happened
101F1first match
101F2second match
102NULLleft row preserved

07 THE SAME CONDITION, A DIFFERENT QUESTION

ON chooses matches.
WHERE chooses survivors.

A right-side filter inside ON still preserves the left row. Move it to WHERE, and the synthetic NULL row can fail the filter.

KEEP EVERY CUSTOMER
LEFT JOIN orders o
  ON o.customer_id = c.id
 AND o.created_at >=
     DATE '2026-07-01'

The date is part of the matching rule. Customers without a recent order remain.

DROP THE NON-MATCHES
LEFT JOIN orders o
  ON o.customer_id = c.id
WHERE o.created_at >=
      DATE '2026-07-01'

The output is filtered after NULL padding. Missing orders cannot satisfy the date predicate.

Cold forecastIf Dee has no orders, which version still emits a Dee row?The ON version.

08 COUNT THE RIGHT THING

COUNT(*) sees output rows.
COUNT(f.id) sees matches.

After a LEFT JOIN, the unmatched customer still owns one result row. COUNT(*) counts it; COUNT(f.id) ignores its NULL right-side value.

Alice
Alice · NULL
COUNT(*)1
COUNT(f.id)0
Bob
Bob · 123
Bob · 456
COUNT(*)2
COUNT(f.id)2

09 PROVING ABSENCE

Use row identity
to prove absence.

For stale orders with no fills at all, test a non-null match key or write the intent directly with NOT EXISTS.

ROBUST

LEFT JOIN anti-join

LEFT JOIN fills f
  ON f.order_id = o.order_id
WHERE f.order_id IS NULL

The joined key can only be NULL when no matching fill row survived.

CLEAR INTENT

Correlated NOT EXISTS

WHERE NOT EXISTS (
  SELECT 1 FROM fills f
  WHERE f.order_id = o.order_id
)

Reads as the business rule: retain the order when no related fill exists.

DATA-DEPENDENT

Nullable attribute

LEFT JOIN fills f
  ON f.order_id = o.order_id
WHERE f.filled_at IS NULL

Also accepts a real fill row whose timestamp happens to be NULL.

Manga panel of Tsumugi inspecting a wall of evidence for a missing rowCASE FILE 02 · PROVE ABSENCE

10 THE FANOUT INCIDENT

Duplicate lookup keys
multiply matching pairs.

ORDERS · UNCHANGED

Four facts

The same four orders in both states
idcustomer_idtotal
CUSTOMERS · TOGGLE THIS

Lookup key grain

The customer lookup before or after the duplicate import
idnamestate
joined rows4stable
SUM(o.total)$500correct

One matching customer row per key keeps the result at the order grain.

WHAT THE DATABASE ACTUALLY RETURNS

One result row per order

KEY IS UNIQUE
The query result, recalculated from the current lookup table
order_idnametotalmatched customer row

11 SYMPTOM HIDING

DISTINCT edits the final projection.

It can collapse identical display rows. It cannot undo a total already multiplied by the join.

PAIR COUNT6 rowstwo Aiko facts repeated
AGGREGATE$660the damage is already counted
FINAL DISTINCTone display totalstill the wrong $660
-- DISTINCT can collapse identical projected customer rows.
SELECT DISTINCT c.id, c.name
FROM orders o
JOIN customers c ON c.id = o.customer_id;

-- It cannot repair an aggregate fed multiplied rows.
SELECT SUM(o.total) AS total
FROM orders o
JOIN customers c ON c.id = o.customer_id;

12 REPAIR THE GRAIN

Repair the relationship at its earliest valid stage.

Choose among a uniqueness constraint, an explicit survivor rule, or pre-aggregation according to the data contract.

ENFORCE

Reject the duplicate

PRIMARY KEY (customer_id)

Correct when the lookup promises one row per customer.

DEDUPLICATE

Choose a survivor

QUALIFY ROW_NUMBER()
  OVER (...) = 1

Correct only when the survivor rule is explicit and auditable.

PRE-AGGREGATE

Match the target grain

GROUP BY order_id

Reduce many fill rows to one order summary before the order-level join.

raw fills
many / order
fill totals
one / order
orders joined
one / order

13 PENCIL DOWN · QUERY UP

Ten forecasts before the answer key.

Define one result row and estimate the row count before writing SQL.

01

Grain contract

State what one row means in accounts and invoices.

Predict: which key may repeat?

02

Duplicated lookup

Invoices are 10→125, 20→80, 10→45, 30→300, 50→60. The lookup contains account 10 twice and no account 50.

Predict: joined rows and SUM(total).

03

Choose the JOIN

Match: only accounts with invoices; every account; dates present in either cash table; every account × date cell.

Predict: INNER, LEFT, FULL, or CROSS.

04

The filter moved

Return members with no login since July 1.

Predict: ON or WHERE for the date?

05

Aggregate first

Find overfilled orders without multiplying order quantities.

Predict: the grain of fill_totals.

06

Count the missing

An account has no invoice match after a LEFT JOIN.

Predict: COUNT(*), COUNT(invoice_id), and their difference.

13B ONE MORE CORE · THREE STRETCH

07

Exists, never refunded

Paid at least once and refunded never.

Predict: one positive and one negative test.

08 · STRETCH

Role + compound match

Join assets twice, then match deposits and trades by user plus date.

Predict: why both predicates are required, though neither guarantees one-to-one matching.

09 · STRETCH

Expected rows

Build a date grid, then find the missing candles.

Predict: CROSS first, anti-join second.

10 · STRETCH

Reconcile and classify

FULL OUTER daily cash flow plus half-open fee tiers.

Predict: the boundary at exactly 100.

Run the companion fixture after every written prediction.Open the answer key ↓

14 DETACHABLE DESK REFERENCE

The eight-question JOIN preflight.

Run this before every production join. If one answer is vague, the query is not ready for an aggregate.

  1. 01What does one row represent in each input?
  2. 02Which key should be unique?
  3. 03How many right rows can match each left row?
  4. 04Which non-matches must survive?
  5. 05Is the right-side filter part of the match or a final filter?
  6. 06What is the output grain after the JOIN?
  7. 07Did aggregation happen before a many-sided JOIN?
  8. 08Can a duplicate-key probe prove the result?
RED FLAGSunexplained row growthDISTINCT as reflexSUM before grain proof

AFTER HOURS MOTION STUDY

The field notes moved.

A five-second Tsumugi fashion study. It is a collectible teaser, not required lesson material.

Vote for more instructor studies

NEXT DROP WHAT SHOULD DROP NEXT?

Practice calendar or instructor fan pack?

Both follow-up ideas are optional. The complete 224-problem browser course remains free.

PRACTICE

Seasonal SQL calendar

A daily SQL forecast with its answer and postmortem, sized for a short practice session.

Vote: SQL calendar
COLLECTIBLE

Instructor fashion pack

High-resolution plates, expression studies, and field-note variants, published separately from the course.

Vote: fan pack

Each link records one anonymous aggregate vote containing only the event name and fixed choice, excluding account data, identifiers, and query text.

APPENDIX A SHARP-PENCIL REVIEW

Answers, with the reason each query holds.

Several SQL shapes can be correct. The invariant is what matters: output grain, match key, and treatment of missing rows.

01 State the grain, then count matches
SELECT a.account_id,
       COUNT(i.invoice_id) AS invoice_matches
FROM accounts a
LEFT JOIN invoices i ON i.account_id = a.account_id
GROUP BY a.account_id
ORDER BY a.account_id;

accounts has one row per account and invoices has one per invoice. The GROUP BY sets the result grain to one row per account. Counting the non-null invoice key preserves Dee with zero matches.

02 Predict the fanout, then prove its cause
SELECT COUNT(*) AS joined_rows,
       SUM(i.total) AS joined_total
FROM invoices i
JOIN account_import a
  ON a.account_id = i.account_id;
SELECT account_id, COUNT(*) AS rows_per_key
FROM account_import
GROUP BY account_id
HAVING COUNT(*) > 1;

The repeated account_id = 10 pairs both Ari invoices with two lookup rows. Four matching invoices become six joined rows and the joined total rises from 550 to 720. The second query identifies the duplicated lookup key.

03 Choose what survives
-- Matching account/invoice pairs only: 4 rows
SELECT COUNT(*)
FROM accounts a JOIN invoices i
  ON i.account_id = a.account_id;

-- Keep every account: 5 rows
SELECT COUNT(*)
FROM accounts a LEFT JOIN invoices i
  ON i.account_id = a.account_id;
-- Build a deliberate 2 x 2 grid: 4 rows
SELECT *
FROM (VALUES (DATE '2026-01-10'), (DATE '2026-01-11')) d(flow_date)
CROSS JOIN (VALUES (10), (20)) a(account_id);

INNER keeps matches. LEFT preserves the account side. CROSS creates every possible pair. FULL OUTER is reserved for reconciliation when unmatched rows from either input must survive.

04 The filter moved
SELECT m.member_id, m.name
FROM members m
LEFT JOIN logins l
  ON l.member_id = m.member_id
 AND l.logged_at >= DATE '2026-07-01'
WHERE l.login_id IS NULL;

The date belongs in ON because it defines a recent-login match. Testing the non-null login key proves that no qualifying login row exists.

05 Aggregate before joining
WITH fill_totals AS (
  SELECT order_id, SUM(quantity) AS filled_quantity
  FROM fills
  GROUP BY order_id
)
SELECT o.order_id, o.quantity, f.filled_quantity
FROM orders o
JOIN fill_totals f ON f.order_id = o.order_id
WHERE f.filled_quantity > o.quantity;

fill_totals is one row per order. The later join therefore cannot repeat an order-level quantity once per raw fill.

06 Count the missing
SELECT a.account_id,
       COUNT(*) AS joined_rows,
       COUNT(i.invoice_id) AS matched_invoices,
       COUNT(*) - COUNT(i.invoice_id) AS missing_invoices
FROM accounts a
LEFT JOIN invoices i ON i.account_id = a.account_id
GROUP BY a.account_id;

The unmatched account owns one output row, zero non-null invoice keys, and therefore one missing relationship.

07 Paid at least once, refunded never
SELECT u.user_id, u.name
FROM users u
WHERE EXISTS (
  SELECT 1 FROM payments p
  WHERE p.user_id = u.user_id AND p.status = 'completed'
)
AND NOT EXISTS (
  SELECT 1 FROM refunds r WHERE r.user_id = u.user_id
);

Membership tests keep each user once regardless of how many payment rows match. EXISTS checks for a completed payment, while NOT EXISTS checks for any refund.

08 Role aliases and a compound match
SELECT t.trade_id, base.name, quote.name
FROM trades t
JOIN assets base  ON base.symbol = t.base_asset
JOIN assets quote ON quote.symbol = t.quote_asset
ORDER BY t.trade_id;
SELECT DISTINCT d.user_id
FROM deposits d
JOIN trades t
  ON t.user_id = d.user_id
 AND t.executed_at::DATE = d.completed_at::DATE
WHERE d.status = 'completed'
ORDER BY d.user_id;

Aliases describe two roles played by the same table. The second relationship needs both user and calendar day; remove either and unrelated facts can pair. Both predicates are required, but neither alone promises one-to-one cardinality.

09 Find missing expected rows
WITH expected AS (
  SELECT p.pair_id, c.trade_date
  FROM pairs p
  CROSS JOIN (
    SELECT DATE '2026-01-01' + CAST(i AS INTEGER) AS trade_date
    FROM range(0, 3) t(i)
  ) c
  WHERE c.trade_date >= p.listed_at
)
SELECT e.pair_id, e.trade_date
FROM expected e
LEFT JOIN candles c
  ON c.pair_id = e.pair_id
 AND c.trade_date = e.trade_date
WHERE c.pair_id IS NULL
ORDER BY e.pair_id, e.trade_date;

The generated calendar and pairs create the rows that should exist. Any expected row left unmatched by the anti-join is a missing candle.

10 Reconcile and classify
WITH dep AS (
  SELECT completed_at AS flow_date,
         SUM(usd_value) AS deposits_usd
  FROM cash_deposits
  WHERE status = 'completed'
  GROUP BY completed_at
), wd AS (
  SELECT completed_at AS flow_date,
         SUM(usd_value) AS withdrawals_usd
  FROM cash_withdrawals
  WHERE status = 'completed'
  GROUP BY completed_at
)
SELECT COALESCE(dep.flow_date, wd.flow_date) AS flow_date,
       COALESCE(dep.deposits_usd, 0)
         - COALESCE(wd.withdrawals_usd, 0) AS net_flow_usd
FROM dep
FULL OUTER JOIN wd ON wd.flow_date = dep.flow_date
ORDER BY flow_date;
SELECT v.user_id, v.volume, f.tier_name
FROM user_volume v
JOIN fee_tiers f
  ON v.volume >= f.min_volume
 AND (v.volume < f.max_volume OR f.max_volume IS NULL)
ORDER BY v.user_id;

FULL OUTER JOIN preserves a date found on either side. The half-open range assigns the exact boundary of 100 to the next tier once, not twice.

Full-size collectible plate
